12
Main switch is used to turn on or turn off
engine.
<TURNING ON HEADLIGHT>
Put main switch key in “ON” position and
turn on headlight switch.
●Position lamp advises approaching
vehicle of the motor cycle position when
operating after sunset. In addition, when
the motor cycle is stopped at night or at
an intersection, the position lamp advises
other vehicles of the motorcycle
existence without blinding operators.
<HEADLIGHT HIGH OR LOW BEAM OPERATION>
High beam or low beam can be operated
by the use of high/low beam switch.
(HI)
...
Headlight placed on high beam
(LO)
...
Headlight placed on low beam
SWITCH OPERATION
MAIN SWITCH
HEADLIGHT·POSITION LAMP
CAUTION
●Do not manipulate main switch key
during operation. If the main switch
key is placed on “Off” or “Lock”
position, all electrical system will
not function. Never operate the
main switch key during travel as it
might cause unexpected accidents,
If it is necessary to remove the
main switch key, stop the vehicle
first prior to removing.
●Prior to dismounting from the
vehicle, make sure to lock the
steering wheel and remove key.
●If the key is left in “ON” position
without starting engine, battery is
discharged.
●Do not use a number of keys
together with a metal key holder.
The keys and the key holder may
cause scratches or other damage to
the cover while operating the
vehicle.(Recommend cloth or
leather key holders)
Switch position
(H)
(P)
Switch position
Headlight, position lamp
and taillight turned on
Position lamp and
taillight turned on.
Light turned off
MAIN SWITCH
Starts engine. Used
to operate vehicle
during day or night
time, to operate
horn, winker, brake
lights or head
lights.
Cannot be
removed
ON
OFF
Can be
removed
Stops engine. Cuts
off all electrical
circuits.
Key
position
Function
Key
removal
( )
**vl125(~47P) 02.11.5 4:33 PM 페이지12
