DAELIM DAYSTAR User Manual

<ADJUSTMENT>
●Drive chain slack slould be checked and
adjusted, if necessary, every 1,000km.
●When operated at sustained high speeds
or under conditions of frequent rapid
acceleration, the chain may requir more
frequent adjustment.
1. Place the motorcycle on its side stand
with the transmission in neutral and the
ignition switch off.
2. Remove the chain tensioner.
3. Loose the axle nut.
4. Loose the lock nuts on both sides of the
swingarm.
5. Turn both adjusting nuts an equal
number of turns until the correct drive
chain slack is obtained. Turn the
adjusting nuts clockwise to tighten the
chain or counter clockwise to provide
more slack.
Rotate the rear wheel and recheck
slack at other section of the chain.
OPTIMA FREE PLAY : 50~60 mm
6. Tighten the axle nut to specified torque.
AXLE NUT TORQUE : 6.0~8.0 kgf
··
m
7. Tighten the adjusting nuts lightly, then
tighten the lock nuts by holding the
adjusting nuts with a spanner.
8. Install the chain tensioner.
32
WARNING
●If a torque wrench is not used for
this installation, see your authorized
dealer as soon as possible to verify
proper assembly.
CAUTION
●If a torque wrench is not used for
this installation, see your authorized
dealer as soon as possible to verify
proper assembly.
●Make sure the right and left chain
adjuster graduations are set in the
same position.
●After adjusting chain, check the
rear brake pedal free play.
●New motorcycle adapts endless-
type drive chain. (end-type for
affer-sales service purpose)
After once disassembling chain,
chain clip can be accidentally
removed, so change new one after
disassembling chain even once.
50~60mm
CHAIN TENSIONER
ADJUSTER
NUT
**vl125(~47P) 02.11.5 4:34 PM 페이지32

DAELIM DAYSTAR Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Engine Type	4-Stroke, Air-cooled
Displacement	124 cc
Transmission	5-speed
Fuel Capacity	12.5 liters
Weight	125 kg
Rear Suspension	Dual shock absorbers
