DAELIM DAYSTAR User Manual

[REAR WHEEL REMOVAL]
① Set vehicle on main stand in upright
position on level ground.
② Loosen the rear brake adjuster nut and
remove the brake rod.
③ Remove the chain tensioner.
④ Loosen the chain adjuster nut.
⑤ Loosen the rear weel axle nut and
remove the rear wheel axle and the rear
wheel.
⑥ Install in the reverse order of removal.
REAR AXLE NUT TORQUE :
6.0~8.0 kgf
··
m
●After installing the wheel, apply the
brake several times and then check if the
wheel rotates freely. Recheck the wheel
if the brake drags or if the wheel does
not rotate freely.
41
WARNING
●If a troque wrench was not used for
installation, see your authorized
dealer as soon as possible to verify
proper assembly.
Improper aseembly may lead to
loss of braking capacity.
BRAKE ARM
BRAKE ROD
CHAIN TENSIONER
REAR WHEEL AXLE
CHAIN
ADJUSTER
NUT
**vl125(~47P) 02.11.5 4:34 PM 페이지41

DAELIM DAYSTAR Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Engine Type	4-Stroke, Air-cooled
Displacement	124 cc
Transmission	5-speed
Fuel Capacity	12.5 liters
Weight	125 kg
Rear Suspension	Dual shock absorbers
