8–22 BODY DIMENSION
Fig. 21
Description
Rear Door x
Roof
Fender x
Front Door
Rear Door x
C Pillar
A pillar x
Front Door
Fender x
Head Lamp
Hood x
Fender
Location
Gap (mm)
ABCDEF
Description
Rear Door x
Side Outer
Side Outer x
Tail Lamp
Trunk Lid x
Side Outer
Location
Gap (mm)
GHI J K L
Front Door x Rear Door
Rocker Panel x
Door
5 ± 1 4
+1
4
+1
3.5
+1
3
+1
1.9
3 ± 1 2 ± 1 5 ± 1 5 ± 1 5 ± 1 3.5
+1
