ROOF, BACK PANEL AND REAR FLOOR PANEL 5–7
2. BACK PANEL
2-1. GENERAL DESCRIPTION
The back panel is joined to the side panel outer, rear
extension longitudinal and extension rear floor. It
forms the base for the rear combination lamps and
other parts and maintains the rigidity of the rear body.
Pay particular attention to twists and parallelism and
check mounting of related parts when welding.
Fig. 8 Back Panel Welding Assembly
