4–6 FRONT
2. FRONT WHEELHOUSE
2-1. GENERAL DESCRIPTION
The front wheelhouse component is constructed as a
unit with the locator shockabsorber. Therefore, replace-
ment of the component affects the front wheel alignment.
When assembling it, either use a jig or follow dimen-
sions on the body repair chart for positioning. It must
be welded carefully.
Fig. 9 Front Wheelhouse Welding Assembly
