2–4 PREPARATIONS OF BODYWORK
3. CORRECTION OF THE DAMAGED
AREA
• Set the frame corrector on the car body.
• The side frame is to allow reshaping by pulling it out.
• Use the horizontal pinch welds for anchoring the car.
Fig. 2
• Apply load to the damaged section and pull it
out until the section is almost restored to the
original shape.
Underbody Clamp Specifications
U-type
• U-Base
• Pro-Tec
• etc.
Frame correctors
C-type
• Korek
• Auto pole
• etc.
Standard type
• Dataliner
• Car-o-liner
• Celette
• Flex-o-liner
• etc.
UNDERBODY CLAMPS
STANDARD TYPE:
C-TYPE:
U-TYPE:
