Local Configurations 188
Click to draw areas to filter the target.
You can configure two filtering targets (maximum size and
minimum size). When the target that is crossing the tripwire is
smaller than the minimum size or larger than the maximum size, no
alarms will be activated. The maximum size should be larger than
the minimum size.
In the Preset list, select the preset that you want to configure the
rule for.
Table 5-47
Drag to draw a tripwire. The tripwire can be a straight line, broken line or polygon. 4)
Click OK to save the settings. 5)
Click to set the actions to be triggered. Step 3
The Trigger interface is displayed. See Figure 5-155.
Figure 5-155
Configure the triggering parameters. See Table 5-48. Step 4
Click Setting to display set interface.
Define a period during which the alarm linkage is active. For
details, see "Setting Motion Detection Period” section in "5.10.4.1
Configuring Motion Detect Settings."
