Dahua Technology LS UCM-EF Series User Manual

Introduction 12
3
Introduction
3.1 LCD Video Wall
The LCD video wall is displayed in Figure 3-1.
Figure 3-1 LCD video wall
3.2 Port
Ports are displayed in Figure 3-2. For detailed parameters, see Table 3-1.
Figure 3-2 Port
Table 3-1 Port description
No.
Port
Function
1
Power output port
Outputs AC current.
2
Power input port
Inputs AC current.
3
Power switch
Controls the on and off of the AC input port.
4
LAN in
An RJ-45 port, inputs RS-232 signals. It controls the screen.
5
LAN out
An RJ-45 port, outputs RS-232 signals.
6
USB2.0 port
For multimedia playing and upgrade.
7
IR port
Connected to the IR extension cord.
