Interface Configuration 15
4
Interface Configuration
Use the remote control to configure parameters for the video wall. Press the menu button, the
menu of the video wall is displayed in Figure 4-1.
Figure 4-1 Menu
For introductions of icons on the interface, see Table 4-1.
Table 4-1 Icon description
Icon
Description
Image icon, used to set imaging effect for the video wall.
Geometric icon, used to set positions for images.
Sound icon, used to adjust volume for the videos played on the video wall.
Advanced icon, used to do advanced settings to images.
Advanced options must be set by professional personnel.
System icon, used to configure parameters for the system.
Input source icon, used to select signal mode.
Press Menu on the remote control, the menu bar is displayed on the video wall, and then
you can adjust relevant parameters.
Press Menu on the remote control or select Menu on the menu bar to exit the current
menu.
