User’s Manual
155
Warning light
Configure the settings for the warning light parameters.
Table 5-29 Warning light parameters
Parameter Description
Channel
In the Channel list, select a channel that is connected to a warning light
camera.
Delay
Set a length of time for the Device to delay turning off alarm after the
alarm is cancelled. The value ranges from 5 seconds to 30 seconds, and
the default value is 5 seconds.
Mode
Set the alarm mode of warning light to be Always on or Flicker.
Flicker Frequency
When setting the alarm mode of warning light to be Flash, you can select
the flash frequency from Low, Middle, and High.
Click Apply to complete the settings.
5.10.3.3 Configuring Siren
When the motion detection alarm is activated, the system links the camera to generate sound alarm.
To use this function, connect at least one camera that supports audio function.
Select Main Menu > ALARM > Alarm-out Port > Siren.
