Dahua HCVR5104C Series User Manual

145
video and multiple-channel data to
the HDMI port of the display
device.
7
Network port
100M Ethernet port
2.2.4 HCVR4104/HCVR4108C-S2/HCVR2108C-S2 Series
The HCVR4104C-S2 series rear panel is shown as below. See Figure 2-15.
Figure 2-15
The HCVR4108C-S2/HCVR2108C-S2 series rear panel is shown as below. See Figure
2-16.
Figure 2-16
Please refer to the following sheet for detailed information.
SN
Icon
Name
Note
1
GND
Ground end
2
USB2.0 port
Connect to USB storage device,
mouse, burning DVD-ROM and
etc.
