USB2.0 port. Connect to mouse, USB storage
device, USB burner and etc.
2.2.33 HCVR58XXS-V2/HCVR48XXS-S2 Series
The rear panel is shown as in Figure 2-79.
The following figure is based on the HCVR5816S-V2 series product.
Figure 2-79
The HCVR4832S-S2 rear panel is shown as in Figure 2-80.
Figure 2-80
Please refer to the following sheet for detailed information.
It is for general COM debug to
configure IP address or
transfer transparent COM
data.
To Next Page
