can connect to the control
devices such as speed dome
PTZ.
11
HDMI
High definition
media interface
High definition audio and video
signal output port. It transmits
uncompressed high definition
video and multiple-channel data
to the HDMI port of the display
device.
12
Network port
100M Ethernet port
2.2.22 HCVR41XXHE-S3/HCVR51XXHE-S3/HCVR71XXH-S3/HCVR71XXHE
-S3 /XVR41XXHE/XVR51XXH/XVR51XXHE/XVR71XXH/XVR71XXHE
Series
The
HCVR41XXHE-S3/HCVR51XXHE-S3/HCVR71XXHE-S3/XVR41XXHE/XVR51H/XVR51
XXHE/XVR71XXHE series rear panel is shown as below. See Figure 4-53.
The following figure is based on HCVR4116HE-S3/HCVR5116HE-S3/HCVR7116HE-S3
/XVR4116HE/XVR5116HE/XVR7116HE series.
Figure 2-55
The HCVR71XXH-S3/XVR71XXH rear panel is shown as below. See Figure 4-52.
The following figure is based on the HCVR7116H-S3/XVR7116H.
