HDCVI Series DVR User’s Manual
25
Parameters
HCVR5104HE-V2
HCVR5108HE-V2
HCVR5116HE-V2
Video Frame
Rate
1536Kbps-4096Kbps，
For 720P: default setup is 2Mbps，max supports 4Mbps
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-channel ， BNC
port
8-channel ， BNC
port
16-channel ， BNC
port
Network Video
Input
N/A
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
4-channel RCA
Audio Output
1-channel RCA
Bidirectional
Talk Input
Support (reuse the audio port)
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Record
Playback
Max 4-channel
playback
Max 8-channel
playback
Max 16-channel
playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
4-channel alarm
input
8-channel alarm
input
16-channel alarm
input
Alarm Output
3-channel alarm output
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD
Space
4T
Coomunication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB ports
Others
Power
DC12V
Power
Consuption
≤30W（With power adapeter, no HDD）
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
Mini 1U case，325mm（W）×245mm（D）×45mm（H）
Weight
1.25KG（No HDD）
Installation
Mode
Desk
1.3.14 HCVR71XXH-V2 Series
Parameters
HCVR7104H-V2
HCVR7108H-V2
System
Main Processor
Industrial embedded micro controller
