Dahua HDCVI series User Manual

HDCVI Series DVR User’s Manual
36
Parameters
HCVR4104HS-S2
HCVR4108HS-S2
HCVR4116HS-S2
Alarm Output
N/A
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD
Space
4T
Coomunication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB ports
Others
Power
DC12V
Power
Consuption
≤15W（With power adapeter, no HDD）
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
Dimensions
Compact 1U case, 260mm（W）×220mm（D）×4 4mm（H）
Weight
1.25KG（No HDD）
Installation
Mode
Desk
1.3.23 HCVR2108HS-S2 Series
Parameters
HCVR2108HS-S2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
720P(1-15f/s)/960H/D1/HD1/2CIF/CIF/QCIF
Video Frame
Rate
HDCVI：1～12f/s
CVBS：1~20f/s（PAL）；1~20f/s（NTSC）
Video Frame
Rate
1024Kbps-4096Kbps，
For 720P: default setup is 1Mbps，max supports 4Mbps.
For 960H: default setup is 1Mbps，max supports 3Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
8-channel，BNC port
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
1-channel RCA port.
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Reuse the audio input/output port.
Record
Record Mode
Schedule record/manual record/MD record/Alarm record

Dahua HDCVI series Specifications

General

HDD Interface	SATA
Video Compression	H.264/H.265
Network Protocols	HTTP; HTTPS; TCP/IP; IPv4/IPv6; SNMP; UPnP; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; P2P
Remote Access	DMSS
Operating Temperature	-10 °C to +55 °C (+14 °F to +131 °F)
Operating Humidity	10% to 90% (non-condensing)
