Parameters
HCVR7104HE-S2
HCVR7108HE-S2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode
Resolution
1080P/720P/960H/D1/HD1/2CIF/CIF/QCIF
Video Frame
Rate
HDCVI：1～25f/s（PAL）；1~30f/s（NTSC）
CVBS：1~25f/s（PAL）；1~30f/s（NTSC）
Video Frame
Rate
2048Kbps-6144Kbps，
For 1080P: default setup is 4Mbps，max supports 6Mbps.
For 720P: default setup is 2Mbps，max supports 4Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode
Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz，16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-channel，BNC port
8-channel，BNC port
Network Video
Input
Max 2-channel IPC connection (16M)
Video Output
1-channel VGA output，
1-channel HDMI output (of the same video source)，
HDMI/ VGA video output at the same time.
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
4-channel RCA port.
Audio Output
1-channel RCA port.
Bidirectional
Talk Input
Reuse the audio input/output port.
Record
Record Mode
Schedule record/manual record/MD record/Alarm record
Record
Playback
Max 4-channel playback
Max 8-channel playback
Backup Mode
HDD, burner, USB device, network backup
Alarm
Alarm Input
8-channel input
16-channel input
Alarm Output
3-channel output
HDD
HDD Port
1 SATA port，does not support eSATA port
One HDD
Space
4T
Coomunication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB ports
Others
Power
DC12V
Power
Consuption
≤15W（With power adapeter, no HDD）
Working
Temperature
-10℃－＋55℃
Working
Humidity
10%~90%
