User’s Manual
160
Parameter
Description
Alarm-out Port
Click
Setting
to display setting interface.
General Alarm: Enable alarm activation through the alarm devices
connected to the selected output port.
External Alarm: Enable alarm activation through the connected
alarm box.
Wireless Siren: Enable alarm activation through devices connected
by USB gateway or camera gateway.
Post-Alarm
Set a length of time for the Device to delay turning off alarm after the
external alarm is cancelled. The value ranges from 0 seconds to 300
seconds, and the default value is 10 seconds. If you enter 0, there will be
no delay.
Show Message
Select the
Show Message
check box to enable a pop-up message in
your local host PC.
Report Alarm
Select the
Report Alarm
check box to enable the system to upload the
alarm signal to the network (including alarm center) when an alarm
event occurs.
Send Email
Select the
Send Email
check box to enable the system to send an email
notification when an alarm event occurs.
To use this function, make sure the email function is enabled in
Main
Menu > NETWORK > Email
.
Record Channel
Select the channel(s) that you want to record. The selected channel(s)
starts recording after an alarm event occurs.
The recording for motion detection and auto recording function must
be enabled. For details, see "5.1.4.9 Configuring Recorded Video Storage
Schedule" and "5.9.1 Enabling Record Control."
PTZ Linkage
Click
Setting
to display the PTZ interface.
Enable PTZ linkage actions, such as selecting the preset that you want
to be called when an alarm event occurs.
Motion Detect can only activate PTZ preset.
Post Record
Set a length of time for the Device to delay turning off recording after
the alarm is cancelled. The value ranges from 10 seconds to 300 seconds,
and the default value is 10 seconds.
Tour Select the
Tour
check box to enable a tour of the selected channels.
Picture Storage
Select the
Snapshot
check box to take a snapshot of the selected
channel.
To use this function, select
Main Menu > CAMERA > Encode >
Snapshot
, in the
Type
list, select
Event
.
