201
Note
When the record type is MD (motion detect), alarm, MD&Alarm, IVS, please enable the
channel record function when corresponding alarm occurs. For example, when the alarm
type is MD, from main menu->Setting->Event->Video Detect->Motion Detect, please select
the record channel and enable record function. See Figure 4-35.
When the record type is MD (motion detect), alarm, MD&Alarm, IVS, refer to chapter 4.7.1
Video detect, chapter 4.7.10 Alarm Settings, and chapter 4.7.3 IVS.
Figure 4-35
c) Please draw manually to set record period. There are six periods in one day. See Figure 4-36.
Note
If you have added a holiday, you can set the record period for the holiday.
To Next Page
