203
Figure 4-37
Step 2 Select a channel to set schedule snapshot.
Step 3 Set snapshot type as schedule. Refer to chapter 4.2.5.3 Snapshot for detailed information.
Step 4 Check the box to set alarm type. See Figure 4-38.
Figure 4-38
Note
When the record type is MD (motion detect), alarm, MD&Alarm, IVS, please enable the
channel snapshot function when corresponding alarm occurs. For example, when the alarm
type is MD, from main menu->Setting->Event->Video Detect->Motion Detect, please select
the snapshot channel and enable snapshot function. See Figure 4-39.
When the snapshot type is MD (motion detect), alarm, MD&Alarm, IVS, refer to chapter 4.7.1
Video detect, chapter 4.7.10 Alarm Settings, and chapter 4.7.3 IVS.
