86
Figure 2-22
The NVR41-8P rear panel is shown as below. See Figure 2-23.
Figure 2-23
The NVR41-W rear panel is shown as below. See Figure 2-24.
Figure 2-24
Please refer to the following sheet for detailed information.
Port Name
Connection
Function
USB2.0 port
USB2.0 port. Connect to mouse, USB storage
device, USB burner and etc.
