Figure 2-24 Front panel
The NVR54-EI / NVR54-16P-EI front panel is shown as below.
Figure 2-25 Front panel
The NVR58-EI/NVR58-16P-EI/NVR48-EI/NVR48-16P-EI front panel is shown as below.
Figure 2-26 Front panel
Table 2-11 Icons
Icon
Name Function
HDD HDD status indicator light
The blue light is on when the HDD
malfunctions.
NET Network status indicator light
The blue light is on when the
network connection is abnormal.
PWR Power status indicator light
The blue light is on when the power
connection is normal.
USB 2.0 port
Connect to peripheral USB 2.0
storage device, mouse, burner and
more.
2.1.13 NVR608-32-4KS2 Series
The following gures are for reference only.
User's Manual
16
