2.2.6 NVR54-4KS2/NVR58-4KS2/NVR54-16P-4KS2/
NVR58-16P-4KS2/NVR54-24P-4KS2/NVR58-16P-4KS2E
The NVR54-4KS2/NVR58-4KS2 series rear panel is shown as below.
Figure 2-58 Rear panel
The NVR54-16P-4KS2/NVR58-16P-4KS2 series rear panel is shown as below.
Figure 2-59 Rear panel
The NVR54-24P-4KS2 series rear panel is shown as below.
Figure 2-60 Rear panel
The NVR54-16P-4KS2E series rear panel is shown as below.
Figure 2-61 Rear panel
The NVR58-16P-4KS2E series rear panel is shown as below.
