Icon Name
NET Network status indicator light
POWER Power status indicator light
USB 2.0 port
Power on-o button
2.1.15 NVR616-4KS2/NVR616-XI/NVR50-EI Series
The following gures are for reference only.
For the product of LCD, the front panel of NVR616-4KS2/NVR616-XI series is shown as below.
Figure 2-29 Front panel
Table 2-14 Icons
No.
Name Function
1 Power button
Press it once to turn on the device.
Press it for a long time to turn o the device.
●
We do not recommend you turn o the device in
this way.
●
Press power button for a long time or pull out the
power cable might result in device auto restart.
2
System HDD indicator
light
The blue light becomes on after system booted up
properly.
In the system HDD, there are device important
conguration le, factory default conguration le,
and device initial boot up data.
User's Manual
18
