Parameter Description
Channel Group
Display all channel groups under the current Window Split setting.
●
Add a channel group: Click Add, in the pop-up Add Group channel,
select the channels to form a group, and then click Save.
●
Delete a channel group: Select the checkbox of any channel group,
and then click Delete.
●
Edit a channel group: Select the checkbox of any channel group and
then click Modify, or double-click on the group. The Modify Channel
Group dialog box is displayed. You can regroup the channels.
●
Click Move up or Move down to adjust the position of channel group.
Step 3 Click Apply to save the settings.
5.16.3 Custom Layout
Background Information
You can set customized video split mode.
●
This function is for some series products. See the actual product for detailed information.
●
Device max. supports 5 customized videos.
Procedure
Step 1 Select Main Menu > DISPLAY > Custom Split.
