No. Function No. Function
7 Network port 8 HDMI port
9
●
NVR608-4K: USB 2.0 port
●
NVR608-4KS2: USB 3.0 port
10 USB 3.0 port
11 eSATA port 12 Ground
2.2.29 NVR616-4KS2/NVR616-XI Series
The general series rear panel of NVR616-4KS2 series is shown as below.
Figure 2-102 Rear panel
The redundant power series rear panel of NVR616-4KS2 series is shown as below.
Figure 2-103 Rear panel
Table 2-44 Ports
No.
Name No. Name
1 Power on-o button 2 Power socket
3 1000M ber port 4 Network port
User's Manual
71
