Port Name Connection Function
GND Ground end.
PoE PORTS PoE port
Built-in switch. Support PoE function.
For PoE series product, you can use this port to provide
power to the network camera.
2.2.3 NVR22-4KS2/NVR22-P-4KS2/NVR22-8P-4KS2//
NVR22-4KS3/NVR22-P-4KS3/NVR22-8P-4KS3/
NVR22-16P-4KS3 Series
The NVR22-4KS2 series rear panel is shown as below.
Figure 2-40 Rear panel
The NVR22-P-4KS2 series rear panel is shown as below.
Figure 2-41 Rear panel
The NVR22-8P-4KS2 series rear panel is shown as below.
Figure 2-42 Rear panel
The NVR22-4KS3 series rear panel is shown as below.
Figure 2-43 Rear panel
The NVR22-P-4KS3 series rear panel is shown as below.
User's Manual
27
