No. Name No. Name
5 eSATA Port 6
HDMI Port
High-denition decoding card is not
installed in standard hardware
conguration, you can purchase as
needed.
7 VGA Port 8 AUDIO IN, RCA Connector
9 AUDIO OUT, RCA Connector 10 RS-232 Port
2.2.31 NVR11HS-W-S2-CE/NVR11HS-W-S2-FCC Series
Figure 2-107 Rear panel
Table 2-47 Ports
Icon
Name Function
USB 2.0 port
USB 2.0 port. Connect to mouse, USB storage
device, USB burner and more.
User's Manual
74
