The NVR54-16P-EI series rear panel is shown as below.
Figure 2-110 Rear panel
The NVR58-16P-EI series rear panel is shown as below.
Figure 2-111 Rear panel
The NVR54-XI series rear panel is shown as below.
Figure 2-112 Rear panel
The NVR58-XI series rear panel is shown as below.
Figure 2-113 Rear panel
Table 2-48 Rear panel description
Icon
Name Function
Power switch Power on-o button
Power input port Input 100–240 VAC.
User's Manual
76
