Dahua XVR4108C-S2 User Manual

88
Model
Parameters
HCVR4224L-S2
HCVR4232L-S2
Audio Output
1-ch,RCA port
Bidirectional
Talk Input
Support（Reuse the audio port）
Record
Record Mode
Auto record, manual record, motion detect record, alarm record
Record
Playback
Max 16-ch playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
16-channel alarm input
Alarm Output
3-channel alarm output
HDD
HDD Port
2 SATA ports. Does not support eSATA port.
Space/HDD
4T
Communication
Port
Network
1 RJ45 port, 1000Mbps Ethernet port
Communication
1 RS232 port, 1 RS485 port
USB
2 USB ports
Other
Power
DC12V/5A
Power
Consumption
≤30W（With adapter, no HDD）
Working
Temperature
-10℃～＋55℃
Working
Humidity
10%~90%
Dimension
1.5U case,440mm（W）×410mm（D）×70mm（H）
Weight
4.5-5.5kg（no HDD）
Installation
Mode
Desk/rack installation
1.3.50 HCVR44XXL-S2 Series
Model
Parameters
HCVR4404L-S2
HCVR4408L-S2
HCVR4416L-S2
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode
Resolution
720P/960H/D1/HD1/2CIF/CIF/QCIF (for sub-stream only)
Video Frame
Rate
HDCVI:1～15f/s（The 1st channel supports 25/30f/s）
CVBS:1~25f/s（PAL）; 1~30f/s（NTSC）
Video Bit Rate
1536Kbps-4096Kbps,
For 720P:default value is 2Mbps,max value is 4Mbps
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
