Dahua XVR4108C-S2 User Manual

91
Model
Parameters
HCVR4424L-S2
HCVR4432L-S2
Alarm
Alarm Input
16-ch alarm input
Alarm Output
6-ch alarm output
HDD
HDD Port
4 SATA ports. Does not support eSATA port
Space/HDD
6T
Communication
Port
Network
1 RJ45 port, 1000Mbps Ethernet port
Communication
1 RS232 port, 1 RS422 port
USB
3 USB ports (One at the front panel and two at the rear panel)
Other
Power
AC110~240V 50+2%HZ (max 220W)
Power
Consumption
≤35W（exclude HDD）
Working
Temperature
-10℃～＋55℃
Working
Humidity
10%~90%
Dimension
1.5U case,440mm（W）×410mm（D）×70mm（H）
Weight
4.5kg～5.5kg（exclude HDD）
Installation
Mode
Desk/rack installation
1.3.51 HCVR48XXS-S2 Series
Model
Parameters
HCVR4804S-S2
HCVR4808S-S2
HCVR4816S-S2
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode
Resolution
720P/960H/D1/HD1/2CIF/CIF/QCIF (for sub-stream only)
Video Frame
Rate
HDCVI:1～15f/s（The 1st channel supports 25/30f/s）
CVBS:1~25f/s（PAL）; 1~30f/s（NTSC）
Video Bit Rate
1536Kbps-4096Kbps,
For 720P:default value is 2Mbps,max value is 4Mbps
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Encode
Standard
G.711A, G.711U, PCM
Audio Sampling
Rate
8KHz,16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch, BNC port
8-ch, BNC port
16-ch, BNC port
