Dahua XVR4108C-S2 User Manual

122
Model
Parameters
XVR4204A
XVR4208A
XVR4216A
Playback Mode
Instant playback, normal playback, event playback, mark playback,
smart playback
Record
Playback
Max 4-ch playback
Max 8-ch playback
Max 16-ch
playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
8-ch alarm input
8-ch alarm input
16-ch alarm
input
Alarm Output
3-ch alarm output
HDD
HDD Port
2 SATA ports. Does not support eSATA port.
Space/HDD
6T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB2.0 ports(One at the front panel and one at the rear panel)
Other
Power
DC12V
Power
Consumption
（No HDD）
≤7W
≤8W
≤10W
Working
Temperature
-10℃～＋55℃
Working
Humidity
10%~90%
Dimension
1U case,375mm（W）×280mm（D）×50mm（H）
Weight
（No HDD）
≤1.5KG
≤1.65KG
≤1.8KG
Installation
Mode
Desk installation
1.3.68 XVR42XXAN Series
Model
Parameters
XVR4204AN
XVR4208AN
XVR4216AN
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode
Resolution
1080N/720P/960H/
D1/HD1/2CIF/CIF
1080N@12fps/720P@15fps/960H/D1/HD1/
2CIF/CIF/
Video Frame
Rate
PAL:1~25f/s; NTSC:1~30f/s
Video Bit Rate
32Kbps～4096Kbps
Bit Stream
Type
Video stream/composite stream
Dual-Stream
Support
