Dahua XVR4108C-S2 User Manual

162
Parameters
XVR4104C-S2
XVR4108C-S2
Alarm
Alarm Input
N/A
Alarm Output
N/A
HDD
HDD Port
1 SATA port,does not support eSATA port
One HDD Space
8T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
RS485
Communication
N/A
USB
2 USB2.0 ports( at the rear panel)
Others
Power
DC12V
Power Consumption
(No HDD)
≤7W
≤8W
Working
Temperature
-10℃～＋55℃
Working Humidity
10%~90%
Dimensions
SMART 1U case, 270mm（W）×205mm（D）×41mm（H）
Weight （No HDD）
≤0.5KG
≤0.55KG
Installation Mode
Desk
1.3.87 XVR510XC-S2 Series
Parameters
XVR5104C-S2
XVR5108C-S2
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264
Encode Resolution
4M Lite/1080P@15fps/1080N/720P/960H/D1/HD1/2CIF/CIF
Video Frame Rate
PAL:1~25f/s; NTSC:1~30f/s
Video Bit Rate
32Kbps-6144Kbps
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode Standard
G.711A/G.711U/PCM/AAC (AAC for the first channel only)
Audio Sampling
Rate
8KHz,16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video Input
4-ch BNC port(CVBS/CVI/AHD
/other analog HD video
self-adaptive)
8-ch BNC
port(CVBS/CVI/AHD/other
analog HD video self-adaptive)
Network Video Input

There is no IP channel by
default. Max add 2 IP channel
connections

Analog/digital channel switch.
Max 6 IP channel connections

There is no IP channel by
default. Max add 4 IP
channel connections

Analog/digital channel
switch. Max 12 IP channel
