Dahua XVR4108C-S2 User Manual

94
Model
Parameters
HCVR4824S-S2
HCVR4832S-S2
Space/HDD
6T
Communication
Port
Network
2 RJ45 ports, 1000Mbps Ethernet ports
Communication
1 RS232 port, 1 RS422 port
USB
4 USB ports (Two at the front panel and two at the rear panel)
Other
Power
AC110~240V 50+2%HZ (Max 220W)
Power
Consumption
≤35W（exclude HDD）
Working
Temperature
-10℃～＋55℃
Working
Humidity
10%~90%
Dimension
2U case,440mm（W）×460mm（D）×89mm（H）
Weight
7.0kg～8.0kg（exclude HDD）
Installation
Mode
Desk/rack installation
1.3.52 HCVR58XXS-V2 Series
Model
Parameters
HCVR5804S-V2
HCVR5808S-V2
HCVR5816S-V2
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode
Resolution
720P/960H/D1/HD1/2CIF/CIF/QCIF (for sub-stream only)
Video Frame
Rate
PAL:1~25f/s; NTSC:1~30f/s
Video Bit Rate
1536Kbps-4096Kbps,
For 720P:default value is 2Mbps,max value is 4Mbps
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Encode
Standard
G.711A, G.711U, PCM
Audio Sampling
Rate
8KHz,16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch, BNC port
8-ch, BNC port
16-ch, BNC port
Network Video
Input
Switch 2 analog channels to the IP channels（8Mbps）
