Dahua XVR4108HS User Manual

96
Model
Parameters
HCVR7104H-4M
HCVR7108H-4M
HCVR7116H-4M
Encode
Resolution
Main stream:
2K(2560*1440)@15f/1080P/720P/960H/D1/HD1/BCIF/CIF/QCIF
Sub stream: D1/CIF/QCIF
Video Frame Rate
2K resolution: PAL:1~15f/s; NTSC:1~15f/s
Other resolutions: PAL:1~25f/s; NTSC:1~30f/s
Video Bit Rate
32Kbps-6144Kbps,
For 720P: default setup is 2Mbps,max supports 4Mbps.
For 1080N: default setup is 4Mbps,max supports 6Mbps.
For 2K: non realtime default setup is 4Mbps,max supports 6Mbps.
Bit Stream Type
Video stream/composite stream
Dual-Stream
Support
Audio
Parameters
Encode Standard
G.711A/G.711U/PCM
Audio Sampling
Rate
8KHz,16Bit
Audio Bit Rate
64Kbps
Video Port
Analog Video
Input
4-ch BNC port
(HDCVI/CVBS)
8-ch BNC port
(HDCVI/CVBS)
16-ch BNC port
(HDCVI/CVBS)
Network Video
Input
 Max add 2 IP
channel
connection.
 Analog
/digital channel
switch. Max 6 IP
channel
connections
 Connection
bandwidth:8Mbp
s-24Mbps
 Max add 4 IP
channel
connection.
 Analog
/digital channel
switch. Max 12
IP channel
connections
 Connection
bandwidth:16
Mbps-48Mbps
 Max add 8 IP
channel
connection.
 Analog
/digital channel
switch. Max 24 IP
channel
connections
 Connection
bandwidth:32Mbps-
96Mbps
Video Output
1-channel VGA output,
1-channel HDMI output, max 4K(3840*2160)@30f
HDMI/ VGA video output at the same time (of the same video source
or different video source).
Loop Output
N/A
Matrix Output
When the HDMI and VGA are of different video output, system
supports one matrix output.
Audio Port
Audio Input
1-channel RCA port.
Coaxial Audio
Input
N/A
Audio Output
1-channel RCA port.
Bidirectional Talk
Input
Reuse the audio input/output port
Record
Record Mode
Schedule record/manual record/MD record/Alarm record/intelligent

Dahua XVR4108HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
USB	2 USB 2.0
Power Supply	DC12V/2A
Main Processor	Embedded Processor
Operating System	Embedded LINUX
HDCVI Camera	1080p@25/30 fps, 720p@25/30 fps
AHD Camera	1080p@25/30 fps, 720p@25/30 fps
TVI Camera	1080p@25/30 fps, 720p@25/30 fps
Record Mode	Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
Video Output	1 HDMI, 1 VGA
Display Split	1/4/8/9
OSD	Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Smart Phone	iPhone, iPad, Android
HDD	1 SATA Port, up to 6TB
Video Input	8 channels
IP Camera Input	8+2 channel, each channel up to 5MP
Recording Resolution	1080N, 720P, 960H, D1, HD1, CIF
Record Rate	Main Stream: 1080N/720P/960H/D1/HD1/BCIF/CIF/QCIF (1~25/30fps)
Bit Rate	32 Kbps–6144 Kbps per channel
Record Interval	1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
Resolution	1920×1080, 1280×1024, 1280×720
Network Interface	RJ-45 port (10/100M)
Interoperability	ONVIF
Working Environment	-10°C to +55°C / 10% to 90% RH
Weight	0.75kg (without HDD)
Two-way Talk	Reuse audio input/output channel 1
