Dahua XVR4108HS User Manual

122
Model
Parameters
XVR4204A
XVR4208A
XVR4216A
Playback Mode
Instant playback, normal playback, event playback, mark playback,
smart playback
Record
Playback
Max 4-ch playback
Max 8-ch playback
Max 16-ch
playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
8-ch alarm input
8-ch alarm input
16-ch alarm
input
Alarm Output
3-ch alarm output
HDD
HDD Port
2 SATA ports. Does not support eSATA port.
Space/HDD
6T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB2.0 ports(One at the front panel and one at the rear panel)
Other
Power
DC12V
Power
Consumption
（No HDD）
≤7W
≤8W
≤10W
Working
Temperature
-10℃～＋55℃
Working
Humidity
10%~90%
Dimension
1U case,375mm（W）×280mm（D）×50mm（H）
Weight
（No HDD）
≤1.5KG
≤1.65KG
≤1.8KG
Installation
Mode
Desk installation
1.3.68 XVR42XXAN Series
Model
Parameters
XVR4204AN
XVR4208AN
XVR4216AN
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode
Resolution
1080N/720P/960H/
D1/HD1/2CIF/CIF
1080N@12fps/720P@15fps/960H/D1/HD1/
2CIF/CIF/
Video Frame
Rate
PAL:1~25f/s; NTSC:1~30f/s
Video Bit Rate
32Kbps～4096Kbps
Bit Stream
Type
Video stream/composite stream
Dual-Stream
Support

Dahua XVR4108HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
USB	2 USB 2.0
Power Supply	DC12V/2A
Main Processor	Embedded Processor
Operating System	Embedded LINUX
HDCVI Camera	1080p@25/30 fps, 720p@25/30 fps
AHD Camera	1080p@25/30 fps, 720p@25/30 fps
TVI Camera	1080p@25/30 fps, 720p@25/30 fps
Record Mode	Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
Video Output	1 HDMI, 1 VGA
Display Split	1/4/8/9
OSD	Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Smart Phone	iPhone, iPad, Android
HDD	1 SATA Port, up to 6TB
Video Input	8 channels
IP Camera Input	8+2 channel, each channel up to 5MP
Recording Resolution	1080N, 720P, 960H, D1, HD1, CIF
Record Rate	Main Stream: 1080N/720P/960H/D1/HD1/BCIF/CIF/QCIF (1~25/30fps)
Bit Rate	32 Kbps–6144 Kbps per channel
Record Interval	1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
Resolution	1920×1080, 1280×1024, 1280×720
Network Interface	RJ-45 port (10/100M)
Interoperability	ONVIF
Working Environment	-10°C to +55°C / 10% to 90% RH
Weight	0.75kg (without HDD)
Two-way Talk	Reuse audio input/output channel 1
