e) System only checks start address if you add IP address. System check start
address and end address if you add IP section and the end address shall be
larger than the start address.
f) System may check newly added IP address exists or not. System does not add if
input IP address does not exist.

Delete: Click it to remove specified item.

Edit: Click it to edit start address and end address. See Figure 5- 149. System can
check the IP address validity after the edit operation and implement IPv6 optimization.

Default: Click it to restore default setup. In this case, the trusted sites and blocked
sites are both null.
Step 4 Click Save to complete setup.

If you enabled trusted sites, only the IP in the trusted sites list can access the
device.

If you enabled blocked sites, the IP in the blocked sites cannot access the
device.
Figure 5- 148
Figure 5- 149
5.11 Information
5.11.1 Version
Here you can view record channel, alarm input/output information, software version,
release date and etc.

Dahua XVR4108HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
USB	2 USB 2.0
Power Supply	DC12V/2A
Main Processor	Embedded Processor
Operating System	Embedded LINUX
HDCVI Camera	1080p@25/30 fps, 720p@25/30 fps
AHD Camera	1080p@25/30 fps, 720p@25/30 fps
TVI Camera	1080p@25/30 fps, 720p@25/30 fps
Record Mode	Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
Video Output	1 HDMI, 1 VGA
Display Split	1/4/8/9
OSD	Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Smart Phone	iPhone, iPad, Android
HDD	1 SATA Port, up to 6TB
Video Input	8 channels
IP Camera Input	8+2 channel, each channel up to 5MP
Recording Resolution	1080N, 720P, 960H, D1, HD1, CIF
Record Rate	Main Stream: 1080N/720P/960H/D1/HD1/BCIF/CIF/QCIF (1~25/30fps)
Bit Rate	32 Kbps–6144 Kbps per channel
Record Interval	1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
Resolution	1920×1080, 1280×1024, 1280×720
Network Interface	RJ-45 port (10/100M)
Interoperability	ONVIF
Working Environment	-10°C to +55°C / 10% to 90% RH
Weight	0.75kg (without HDD)
Two-way Talk	Reuse audio input/output channel 1
