Dahua XVR4108HS User Manual

95
Model
Parameters
HCVR5804S-V2
HCVR5808S-V2
HCVR5816S-V2
Video Output
1-ch VGA output,
1-ch HDMI output,
1-ch TV output,
HDMI/ VGA/TV video output at the same time (VGA/HDMI/TV of the
same video source)
Loop Output
N/A
Matrix Output
N/A
Audio Port
Audio Input
4-ch,BNC port, audio via
coaxial cable
8-ch,BNC port,
audio via coaxial
cable
16-ch,BNC port,
audio via coaxial
cable
Audio Output
1-ch,RCA port
Bidirectional
Talk Input
Support（Independent bidirectional talk port）
Record
Record Mode
Auto record, manual record, motion detect record, alarm record
Record
Playback
Max 4-ch playback
Max 8-ch playback
Max 16-ch
playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
8-ch alarm input
8-ch alarm input
16-ch alarm input
Alarm Output
6-ch alarm output
HDD
HDD Port
8 SATA ports,does not support eSATA port
Space/HDD
4T
Communication
Port
Network
2 RJ45 ports, 1000Mbps Ethernet port
Communication
1 RS232 port, 1 RS422 port, 1 RS485 port
USB
3 USB ports (One at the front panel and two at the rear panel)
Other
Power
AC90~264V 50+2% Hz (Max 220W)
Power
Consumption
≤35W（exclude HDD）
Working
Temperature
-10℃～＋55℃
Working
Humidity
10%~90%
Dimension
2U case,440mm（W）×460mm（D）×89mm（H）
Weight
7.0kg～8.0kg（exclude HDD）
Installation
Mode
Desk/rack installation
1.3.53 HCVR71XXH-4M Series
Model
Parameters
HCVR7104H-4M
HCVR7108H-4M
HCVR7116H-4M
System
Main Processor
Industrial embedded micro controller
OS
Embedded LINUX
Video
Parameters
Video Encode
Standard
H.264+/H.264

Dahua XVR4108HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
USB	2 USB 2.0
Power Supply	DC12V/2A
Main Processor	Embedded Processor
Operating System	Embedded LINUX
HDCVI Camera	1080p@25/30 fps, 720p@25/30 fps
AHD Camera	1080p@25/30 fps, 720p@25/30 fps
TVI Camera	1080p@25/30 fps, 720p@25/30 fps
Record Mode	Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
Video Output	1 HDMI, 1 VGA
Display Split	1/4/8/9
OSD	Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Smart Phone	iPhone, iPad, Android
HDD	1 SATA Port, up to 6TB
Video Input	8 channels
IP Camera Input	8+2 channel, each channel up to 5MP
Recording Resolution	1080N, 720P, 960H, D1, HD1, CIF
Record Rate	Main Stream: 1080N/720P/960H/D1/HD1/BCIF/CIF/QCIF (1~25/30fps)
Bit Rate	32 Kbps–6144 Kbps per channel
Record Interval	1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
Resolution	1920×1080, 1280×1024, 1280×720
Network Interface	RJ-45 port (10/100M)
Interoperability	ONVIF
Working Environment	-10°C to +55°C / 10% to 90% RH
Weight	0.75kg (without HDD)
Two-way Talk	Reuse audio input/output channel 1
