Dahua XVR4108HS User Manual

69
Model
Parameters
HCVR4204A-
S2
HCVR4208A-
S2
HCVR4216A-
S2
HCVR4216AN
-S2
Record
Record Mode
Auto record, manual record, motion detect record, alarm record
Record
Playback
Max 4-ch
playback
Max 8-ch
playback
Max 16-ch playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
8-ch alarm input
8-ch alarm input
16-ch alarm input
N/A
Alarm Output
3-ch alarm output
N/A
HDD
HDD Port
2 SATA ports. Does not support eSATA port.
Space/HDD
4T
Communication
Port
Network
1 RJ45 port, 100Mbps Ethernet port
Communication
RS485 port
USB
2 USB ports
Other
Power
DC12V/4A
Power
Consumption
≤30W（No HDD）
Working
Temperature
-10℃～＋55℃
Working
Humidity
10%~90%
Dimension
1U case,375mm（W）×280mm（D）×50mm（H）
Weight
1.5-2.5kg（no HDD）
Installation
Mode
Desk installation
1.3.39 HCVR4224/4232AN-S2 Series
Model
Parameters
HCVR4224AN-S2
HCVR4232AN-S2
System
Main Processor
High-performance industrial embedded micro controller
OS
Embedded LINUX
Video
Video Encode
Standard
H.264
Encode
Resolution
720P(1-15fps)/960H/D1/HD1/2CIF/CIF/QCIF (for sub-stream only)
Video Frame
Rate
HDCVI:1～15f/s（The 1
st
/ 2
nd
channel supports 25/30f/s）
CVBS:1~25f/s（PAL）; 1~30f/s（NTSC）
Video Bit Rate
1024Kbps～4096Kbps,
For 720P realtime (The first two channels):default value is
2Mbps,max value is 4Mbps.
For 720P non-realtime: default value is 1Mbps,max value is
2Mbps.
Bit Stream
Type
Video stream/composite stream

Dahua XVR4108HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
USB	2 USB 2.0
Power Supply	DC12V/2A
Main Processor	Embedded Processor
Operating System	Embedded LINUX
HDCVI Camera	1080p@25/30 fps, 720p@25/30 fps
AHD Camera	1080p@25/30 fps, 720p@25/30 fps
TVI Camera	1080p@25/30 fps, 720p@25/30 fps
Record Mode	Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
Video Output	1 HDMI, 1 VGA
Display Split	1/4/8/9
OSD	Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Smart Phone	iPhone, iPad, Android
HDD	1 SATA Port, up to 6TB
Video Input	8 channels
IP Camera Input	8+2 channel, each channel up to 5MP
Recording Resolution	1080N, 720P, 960H, D1, HD1, CIF
Record Rate	Main Stream: 1080N/720P/960H/D1/HD1/BCIF/CIF/QCIF (1~25/30fps)
Bit Rate	32 Kbps–6144 Kbps per channel
Record Interval	1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
Resolution	1920×1080, 1280×1024, 1280×720
Network Interface	RJ-45 port (10/100M)
Interoperability	ONVIF
Working Environment	-10°C to +55°C / 10% to 90% RH
Weight	0.75kg (without HDD)
Two-way Talk	Reuse audio input/output channel 1
