Page #153 background imageLoading...
Page #153 background image
137
Video Port
Analog Video
Input
8-ch BNC port
(HDCVI HD
video/general
standard definition
video self-adaptive)
16-ch BNC
port(HDCVI HD
video/general
standard definition
video self-adaptive)
32-ch BNC
port(HDCVI HD
video/general
standard definition
video self-adaptive)
Network Video
Input
Support 4 IP
channels by
default.
Analog
/digital channel
switch. Max 12
IP channel
connections.
Connection
bandwidth:16M
bps-48Mbps
Support 8 IP
channels by
default.
Analog
/digital channel
switch. Max 24
IP channel
connections.
Connection
bandwidth:32M
bps-96Mbps
There is no IP
channel by
default.
Analog
/digital channel
switch. Max 32
IP channel
connections.
Connection
bandwidth:0Mb
ps-128Mbps
Video Output
1-ch VGA output,
1-ch HDMI output,
1-ch TV output,
HDMI/VGA/TV video
output at the same
time
( HDMI/VGA/TV of
the same video
source)
1-ch VGA output,
2-ch HDMI output,
1-ch TV output,
HDMI1/VGA/TV
video output at the
same time
(HDMI1/VGA/TV
of the same video
source)
1-ch VGA output,
2-ch HDMI output,
1-ch TV output,
HDMI1/VGA/TV
video output at the
same time
(HDMI1/VGA/TV
of the same video
source)
Loop Output
N/A
Matrix Output
N/A
HDMI2 port support matrix output
Audio Port
External
Audio Input
4-channel BNC port,
Coaxial Audio
Input
8-channel
16-channel
32-channel
Audio Output
1-ch BNC port
Bidirectional
Talk Input
SupportIndependent bidirectional talk port
Record
Record Mode
Card number record, mark record, alarm record, motion detection
record, regular record, manual record, intelligent record.
Playback Mode
Instant playback, normal playback, event playback, mark playback,
intelligent playback.
Record
Playback
Max 8-ch playback
Max 16-ch playback
Backup Mode
HDD, burner, flash disk, network backup.
Alarm
Alarm Input
8-channel
16-channel
