Page #538 background imageLoading...
Page #538 background image
522
Parameter
Function
HTTP port
The default value is 80. You can input the actual port number if necessary.
HTTPS
The default value is 443. You can input the actual port number if necessary.
RTSP port
The default value is 554. Please leave it in blank if you are using default
value. When you are using QuickTime or VLC, you can use the following
format. BlackBerry cellphone support this function too.
Real-time monitoring URL format: please require real-time RTSP media
server, require channel number, and bit stream type in URL. You may
need username and password.
When you are using BlackBerry, please set encode mode as H.264B,
resolution to CIF and turn off audio.
URL format is:
rtsp://username:password@ip:port/cam/realmonitor?channel=1&subtype=0
username/password/IP and port.
Username: such as admin.
Password: such as admin.
IP: Device IP such as 10.7.8.122.
Port: Port value. The default setup is 554. You can leave in blank if you
are using default value.
Channel: channel number. It starts with 1. If it is channel 2, then
channel=2.
Subtype: bit stream type. The main stream is 0(subtype-0),subtype is
1(subtype=1).
For example, if you want to get the sub stream of the channel 2, the URL is:
rtsp://admin:admin@10.12.4.84:554/cam/realmonitor?channel=2&subtype=1.
If there is no authentication, there is no need to specify user name and
password, you can use the followinf format:
rtsp://ip:port/cam/realmonitor?channel=1&subtype=0
POS port
The value ranges from 1 to 65535. The default setup is 38800.
5.10.2.3 HTTPS
In this interface, you can set to make sure the PC can successfully login via the HTTPS. It
is to guarantee communication data security. The reliable and stable technology can
secure the user information security and device safety. See Figure 5- 43.
Note
You need to implement server certificate again if you have changed device IP.
You need to download root certificate if it is your first time to use HTTPS on current
PC.
Figure 5- 43

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dahua XVR4108HS and is the answer not in the manual?

Dahua XVR4108HS Specifications

General IconGeneral
Video CompressionH.265+/H.265/H.264+/H.264
Audio Input/Output1/1, RCA
USB2 USB 2.0
Power SupplyDC12V/2A
Main ProcessorEmbedded Processor
Operating SystemEmbedded LINUX
HDCVI Camera1080p@25/30 fps, 720p@25/30 fps
AHD Camera1080p@25/30 fps, 720p@25/30 fps
TVI Camera1080p@25/30 fps, 720p@25/30 fps
Record ModeManual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
Video Output1 HDMI, 1 VGA
Display Split1/4/8/9
OSDCamera title, Time, Video loss, Camera lock, Motion detection, Recording
Smart PhoneiPhone, iPad, Android
HDD1 SATA Port, up to 6TB
Video Input8 channels
IP Camera Input8+2 channel, each channel up to 5MP
Recording Resolution1080N, 720P, 960H, D1, HD1, CIF
Record RateMain Stream: 1080N/720P/960H/D1/HD1/BCIF/CIF/QCIF (1~25/30fps)
Bit Rate32 Kbps–6144 Kbps per channel
Record Interval1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
Resolution1920×1080, 1280×1024, 1280×720
Network InterfaceRJ-45 port (10/100M)
InteroperabilityONVIF
Working Environment-10°C to +55°C / 10% to 90% RH
Weight0.75kg (without HDD)
Two-way TalkReuse audio input/output channel 1
