Step 3 Double click a name to connect to it.
Click Refresh button, you can view latest connection status.
5.10.2.5 3G/4G
It is to connect to the 3G/4G network to receive alarm information, view device state,
audio/video and etc.
5.10.2.5.1 CDMA/GPRS
Step 1 From main window->Setup->Network->3G/4G.
Enter 3G/4G interface is shown as in Figure 5- 55.
Note
After you connected the 3G/4G module, you can view the module information and
wireless signal. If there is no information, click Search button to search.
Figure 5- 55
Step 2 Check the Boot up box to enable this function and then set parameters.
Parameter
Function
WLAN type
Here you can select 3G/4G network type to distinguish the
3G/4G module from different ISP. The types include
WCDMA,CDMA1x and etc.
APN/Dial No.
Here is the important parameter of PPP.
Authorization
It includes PAP,CHAP,NO_AUTH.
Pulse interval
It is to set time to end 3G/4G connection after you close extra
stream monitor. For example, if you input 60 here, system ends
3G/4G connection after you close extra stream monitor 60
seconds.
Important

If the pulse interval is 0, then system does not end 3G/4G connection
after you close the extra stream monitor.

Dahua XVR4108HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
USB	2 USB 2.0
Power Supply	DC12V/2A
Main Processor	Embedded Processor
Operating System	Embedded LINUX
HDCVI Camera	1080p@25/30 fps, 720p@25/30 fps
AHD Camera	1080p@25/30 fps, 720p@25/30 fps
TVI Camera	1080p@25/30 fps, 720p@25/30 fps
Record Mode	Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
Video Output	1 HDMI, 1 VGA
Display Split	1/4/8/9
OSD	Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Smart Phone	iPhone, iPad, Android
HDD	1 SATA Port, up to 6TB
Video Input	8 channels
IP Camera Input	8+2 channel, each channel up to 5MP
Recording Resolution	1080N, 720P, 960H, D1, HD1, CIF
Record Rate	Main Stream: 1080N/720P/960H/D1/HD1/BCIF/CIF/QCIF (1~25/30fps)
Bit Rate	32 Kbps–6144 Kbps per channel
Record Interval	1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
Resolution	1920×1080, 1280×1024, 1280×720
Network Interface	RJ-45 port (10/100M)
Interoperability	ONVIF
Working Environment	-10°C to +55°C / 10% to 90% RH
Weight	0.75kg (without HDD)
Two-way Talk	Reuse audio input/output channel 1
