Dahua XVR4108HS User Manual

531
Figure 5- 58
Please refer to the following sheet for detailed information.
Parameter
Function
DDNS Type
Server name and address provided by the DDNS service
provider.

Dyndns DDNS is members.dyndns.org.

NO-IP DDNS is dynupdate.no-ip.com.

CN99 DDNS is members.3322.org.
Server IP
Domain Name
The domain name registered on the DDNS service provider
website.
User
Input the user name and password got from the DDNS service
provider. Make sure you have logged in the DDNS service
provider website to register an account (user name and
password).
Password
Update period
After DDNS boots up, it sends out refresh query regularly. The
unit is minute.
After setting, click Save button.
Input full domain name on the browser and click Enter button. The setting is right if you
can view device WEB interface. Otherwise, please check the parameters.
5.10.2.8 Sync Time Right
It is to allow the specified IP host to sync time with the device or change device time.
Background Information
If the IP host and the device are not the same, it may result in file search failure; data
backup is not the same and cannot record and operate the device. So, there is need to
specify the device and IP host time synchronization mechanism and make sure the device
and IP host time is the same.

Dahua XVR4108HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
USB	2 USB 2.0
Power Supply	DC12V/2A
Main Processor	Embedded Processor
Operating System	Embedded LINUX
HDCVI Camera	1080p@25/30 fps, 720p@25/30 fps
AHD Camera	1080p@25/30 fps, 720p@25/30 fps
TVI Camera	1080p@25/30 fps, 720p@25/30 fps
Record Mode	Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
Video Output	1 HDMI, 1 VGA
Display Split	1/4/8/9
OSD	Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Smart Phone	iPhone, iPad, Android
HDD	1 SATA Port, up to 6TB
Video Input	8 channels
IP Camera Input	8+2 channel, each channel up to 5MP
Recording Resolution	1080N, 720P, 960H, D1, HD1, CIF
Record Rate	Main Stream: 1080N/720P/960H/D1/HD1/BCIF/CIF/QCIF (1~25/30fps)
Bit Rate	32 Kbps–6144 Kbps per channel
Record Interval	1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
Resolution	1920×1080, 1280×1024, 1280×720
Network Interface	RJ-45 port (10/100M)
Interoperability	ONVIF
Working Environment	-10°C to +55°C / 10% to 90% RH
Weight	0.75kg (without HDD)
Two-way Talk	Reuse audio input/output channel 1
