Dahua XVR4108HS User Manual

577
Parameter
Function
Port
It is to set the time server port.
Interval
It is to set the sync periods between the device and the time server.
5.10.5.1.3 Holiday Setup
Holiday setup interface is shown as in Figure 5- 115.
Here you can click Add box to add a new holiday and then click Save button to save.
Note
Once the holiday settings is different the general date, the holiday settings has priority.
After successfully set holiday here, you can view holiday item in Schedule interface. It is
for you to set holiday schedule record/snapshot settings.
Figure 5- 115
5.10.5.2 Display
Display interface includes GUI, TV adjust, Tour and zero-channel encoding.
5.10.5.2.1 Display
Here you can set background color and transparency level. See Figure 5- 116.
Figure 5- 116

Dahua XVR4108HS Specifications

General

Video Compression	H.265+/H.265/H.264+/H.264
Audio Input/Output	1/1, RCA
USB	2 USB 2.0
Power Supply	DC12V/2A
Main Processor	Embedded Processor
Operating System	Embedded LINUX
HDCVI Camera	1080p@25/30 fps, 720p@25/30 fps
AHD Camera	1080p@25/30 fps, 720p@25/30 fps
TVI Camera	1080p@25/30 fps, 720p@25/30 fps
Record Mode	Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop
Video Output	1 HDMI, 1 VGA
Display Split	1/4/8/9
OSD	Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Smart Phone	iPhone, iPad, Android
HDD	1 SATA Port, up to 6TB
Video Input	8 channels
IP Camera Input	8+2 channel, each channel up to 5MP
Recording Resolution	1080N, 720P, 960H, D1, HD1, CIF
Record Rate	Main Stream: 1080N/720P/960H/D1/HD1/BCIF/CIF/QCIF (1~25/30fps)
Bit Rate	32 Kbps–6144 Kbps per channel
Record Interval	1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
Resolution	1920×1080, 1280×1024, 1280×720
Network Interface	RJ-45 port (10/100M)
Interoperability	ONVIF
Working Environment	-10°C to +55°C / 10% to 90% RH
Weight	0.75kg (without HDD)
Two-way Talk	Reuse audio input/output channel 1
