System setting
Menu Name
Example: Scheduling
Reference
Determining Schedule
Events
3. [ In this step you will determine schedule events for the zone “2F.” ]
Note: These events are provided only for reference. Create customized
schedules based on your actual requirements.
See page [42]
See page [44]
Copying or Deleting
Schedule Programs
You can copy or delete existing schedule programs.
See page [45]
Copying or Deleting
Schedule Events
You can copy or delete existing schedule events.
See page [46]
Naming a Schedule You can change a default schedule name to a descriptive one. See page [47]
Example: event settings for Mon to Fri
Example: event settings for Sat and Sun
Example: event settings for Ex1 (third Sat of each month)
Example: event settings for Ex2 (for example, summer holidays)
Example: event settings for Ex3 (M. 12 D. 28)
Example: event settings for Ex4 (M. 1 D. 5)
∗ “Null” indicates that the previous state is maintained in the time frame.
Time Target Zone Start/Stop
Opera-
tion mode
Set
temperature
Remote Controller Code
8:30 Zone 2F ON Null Null Override
12:00 Zone 2F OFF Null Null Null
13:00 Zone 2F ON Null Null Override
17:00 Zone 2F Null Null Null
Permits only stopping
22:00 Zone 2F OFF Null Null Prohibits remote controller operations
Time Target Zone Start/Stop
Opera-
tion mode
Set
temperature
Remote Controller Code
9:00 Zone 2F Null Null Null Override
17:00 Zone 2F OFF Null Null
Prohibits remote controller operations
Time Target Zone Start/Stop
Opera-
tion mode
Set
temperature
Remote Controller Code
8:30 Zone 2F ON Null Null Override
12:00 Zone 2F OFF Null Null Null
13:00 Zone 2F ON Null Null Override
17:00 Zone 2F Null Null Null
Permits only stopping
22:00 Zone 2F OFF Null Null Prohibits remote controller operations
Time Target Zone Start/Stop
Operation
mode
Set
temperature
Remote Controller Code
9:00 Zone 2F Null Null Null Override
17:00 Zone 2F OFF Null Null
Prohibits remote controller operations
Time Target Zone Start/Stop
Operation
mode
Set
temperature
Remote Controller Code
9:00 Zone 2F ON HEAT 25°C
Override
Prohibits temperature setting
Prohibits operation mode setting
12:00 Zone 2F OFF Null Null Prohibits remote controller operations
Time Target Zone Start/Stop
Operation
mode
Set
temperature
Remote Controller Code
10:00 Zone 2F ON HEAT 25°C
Override
Prohibits temperature setting
Prohibits operation mode setting
12:00 Zone 2F OFF Null Null Null
13:00 Zone 2F ON Null 25°C
Override
Prohibits temperature setting
Prohibits operation mode setting
15:00 Zone 2F OFF Null Null Prohibits remote controller operations
