Daikin DPSA - PHYSICAL DATA; Table 1: Physical Data

CAT 258 • REBEL APPLIED ROOFTOP 20 www.DaikinApplied.com


Table 1: Rebel Applied 031 – 052 Physical Data
 31 35 40 50 52
󰀩
Staged Control Qty - hp 4 – 5 4-7.5 4-9 4-10 4-11.5
Capacity Control 0/25/50/75/100

Qty/Diam/HP 4/26"/1.5

Rows/FPI 4 or 6 rows/ 12 FPI
FA (sqft) - Standard 26.5 26.5 35.4 35.4 35.4
FA (Sqft) - Optional 35.4 35.4 26.5 26.5 26.5
Circuits 2, Fully Interlaced

FA (sqft) 110
Type Microchannel

Type Direct-dive ECM SWSI Plenum Fan Array
Row × Columns (Qty) 1 × 2 (2) or 2 × 2 (4)
Diameter (in) 14", 18", 20", 22", 25"
Motor Range kw (hp) 1.1 kW – 9.8 kW

Type Direct-dive ECM SWSI Plenum Fan Array
Row × Columns (Qty) 1 × 2 (2)
Diameter (in) 18", 20", 22", 25"
Motor Range kw (hp) 1.1 kW – 6.0 kW

Type Direct-dive Propeller Exhaust with VFD
Row × Columns (Qty) 1 × 2 (2), 1 × 3 (3)
Diameter (in) 26" Diam. Propeller Fan
Motor Range (hp) 1.5 HP

Type Direct-dive ECM SWSI Plenum Fan Array
Row × Columns (Qty) 1 × 1 (1), 1 × 2 (2)
Diameter mm (in) 18", 20", 22", 25"
Motor Range kw (hp) 1.1 kW – 6.0 kW

Nom. Input (MBH) 200, 400, 600, 800, 1125
Nom. Output (MBH) 162, 324 ,486, 648, 911
E󰀩ciency 81%

Nom. kW Input (varies by voltage) 20–230kW

FA (sqft)/Rows/Fins 20.6ft² / 1 or 2 row / 8,10,12 FPI
FA (sqft)/Rows/Fins 26.9ft² / 1 or 2 row / 8,10,12 FPI

FA (sqft)/Rows/Fins 20.3 ft² / 1 row / 6,8,10 FPI
FA (sqft)/Rows/Fins 26.6 ft² / 1 row / 6,8,10 FPI
