www.DaikinApplied.com 3 CAT 258 • REBEL APPLIED ROOFTOP
• 30-52 tons with the exibility to serve 100% outdoor air,
dehumidication, and VAV applications
• Thermally broken, double wall foam construction with
R-13 thermal resistance and rigid full length piano hinged
doors.
• Ultra-low air leakage cabinet construction with leakage
rates less than 0.5% of design CFM up to 5” Static
Pressure and less than 1% of design CFM up to 8” of
static pressure.
• ECM fan array technology provides redundancy,
eciency and low sound
• Adaptive cabinet design features customized layouts for
each unique application.
• At a minimum, product performance exceeds Department
of Energy 2023 eciency requirements
• High Eciency options provide EER's over 11.0 and
IEER's up to 17.2.
• Precision heating and cooling temperature and humidity
control with modulating technologies that provide superior
turndown.
• Airow measuring, Filtration, UV lights, and ventilation
controls for optimized Indoor Air Quality
• Fully tested, Factory commissioned job site specic
control set points
• Quiet operation is standard, with options to tailor radiated
and ducted sound performance to each application.
DPSA 050 A 4 B S A S
Daikin Rebel Applied Packaged DX System
Nominal Capacity
031 – 31 Tons 050 – 50 Tons
035 – 35 Tons 052 – 52 Tons
040 – 40 Tons
Design Vintage
A – A Vintage
Voltage
2 – 208V 4 – 460V
3 – 240V 5 – 575V
Cabinet Size
B – B Cabinet
Eciency
S – Standard Eciency
Cooling Modulation
S – Staged Compressors
H – Staged Compressor
with HGBP (Lead Circuit)
B – Staged Compressors with HGBP (All)
Cooling Coil
A – 4 Row Evaporator
B – 6 Row Evaporator
C – 4 Row Evaporator – Small Face
D – 6 Row Evaporator – Small Face
E – 4 Row Evaporator – Small Face
– Bypass Damper
F – 6 Row Evaporator – Small Face
– Bypass DamperCooling Damper
