CAT 258 • REBEL APPLIED ROOFTOP 24 www.DaikinApplied.com
Rebel Applied oers many section variations for application optimization. The section lengths of the dierent features and
arrangements can vary greatly. Use Table 8 as reference for the range of length possible per section and consult your local sales
rep for a weight and length specic to your application needs.
Table 8: Rebel Applied 031 – 052 Weights and Dimensions
Return
0–30% Outside Air
48-172”
100% Outside Air
100% Outside Air with Energy Recovery
0–100% Economizer with Baromtric Releif
0–100% Economizer with Propeller Fans
0–100% Economizer with High Static Exhaust Fans
0–100% Economizer with High Static Return Fans
0–100% Economizer with Energy Recovery
Filter
2" Pleated Filter
8–32"2"/4" Pleated Fileter
2"/12" Cartridge
Hot Water/Steam Preheat
Hot Water
36"
Steam Coil
DX Coil
Modulating Hot Gas Reheat
24"
UV Lights
Reheat Modulating Hot Gas Reheat 12"
Electric Heat Electric Heat 36"
Hot Water/Steam Heat Hot Water/Steam Coil 36"
Backdraft Dampers (2) or (4) Damper 24"
Supply Fan
Blow Through Fan Section
36"
Discharge Fan Section
Gas Heat 200-1125 MBH furnace 40–48"
Final Filters
Side Load Cartridge Filter
32–44"
Face Load Filter
Blank/Access Sections Add up to 6 blank section in 24 to 48" lengths 24–48"
Discharge Plenum Bottom, Right, Left, Top Discharge 40"
Out of Air Stream Vestibule
48" Vestibule Section
48-72"
72" Vestibule Section
