7 Configuration
Installation manual
35
EBSH/X(B)11+16P50D
Daikin Altherma 3 R ECH₂O
4P759878-1 – 2024.01
7.2 Configuration wizard
After first power ON of the system, the user interface starts a
configuration wizard. Use this wizard to set the most important initial
settings for the unit to run properly. If required, you can afterwards
configure more settings. You can change all these settings via the
menu structure.
7.2.1 Configuration wizard: Language
# Code Description
[7.1] N/A Language
7.2.2 Configuration wizard: Time and date
# Code Description
[7.2] N/A Set the local time and date
INFORMATION
By default, daylight savings time is enabled and clock
format is set to 24 hours. If you want to change these
settings, you can do this in the menu structure (User
settings > Time/date) once the unit is initialised.
7.2.3 Configuration wizard: System
Indoor unit type
The indoor unit type is displayed, but cannot be adjusted.
Backup heater type
# Code Description
[9.3.1] [E‑03] ▪ 0: None
▪ 2: 3V
▪ 3: 6V
▪ 4: 9W
Domestic hot water
The system includes an energy storage tank and can prepare
domestic hot water. This setting is read only.
# Code Description
[9.2.1] [E‑05]
[E‑06]
[E‑07]
▪ Integrated
The backup heater will also be used
for domestic hot water heating.
Emergency
When the heat pump fails to operate, the backup heater or boiler can
serve as an emergency heater. It then takes over the heat load
either automatically or by manual interaction.
▪ When Emergency is set to Automatic and a heat pump failure
occurs, the backup heater or boiler automatically takes over the
domestic hot water production and space heating.
▪ When Emergency is set to Manual and a heat pump failure
occurs, the domestic hot water heating and space heating stops.
To manually recover it via the user interface, go to the
Malfunctioning main menu screen and confirm whether the
backup heater can take over the heat load or not.
▪ Alternatively, when Emergency is set to:
▪ auto SH reduced/DHW on, space heating is reduced but
domestic hot water is still available.
▪ auto SH reduced/DHW off, space heating is reduced and
domestic hot water is NOT available.
▪ auto SH normal/DHW off, space heating operates as
normally but domestic hot water is NOT available.
Similarly as in Manual mode, the unit can take the full load with
the backup heater or boiler if the user activates this via the
Malfunctioning main menu screen.
To keep energy consumption low, we recommend to set Emergency
to auto SH reduced/DHW off if the house is unattended for longer
periods.
# Code Description
[9.5.1] [4-06] ▪ 0: Manual
▪ 1: Automatic
▪ 2: auto SH reduced/DHW on
▪ 3: auto SH reduced/DHW off
▪ 4: auto SH normal/DHW off
INFORMATION
The auto emergency setting can be set in the menu
structure of the user interface only.
INFORMATION
If a heat pump failure occurs and Emergency is not set to
Automatic (setting 1), the following functions will remain
active even if the user does NOT confirm emergency
operation:
- Room frost protection
- Underfloor heating screed dryout
However, the disinfection function will be activated ONLY if
the user confirms emergency operation via the user
interface.
INFORMATION
If the boiler is connected as auxiliary heat source to the
tank (via bivalent coil or via drain back connection), the
boiler and NOT the backup heater operates as emergency
heater, independent of the boiler capacity. For small
capacity boilers this may lead to capacity shortages in
case of emergency.
If the boiler is directly connected to the space heating
circuit, it does NOT act as emergency heater.
Number of zones
The system can supply leaving water to up to 2 water temperature
zones. During configuration, the number of water zones must be set.
INFORMATION
Mixing station. If your system layout contains 2 LWT
zones, you need to install a mixing station in front of the
main LWT zone.
