Daikin Enfinity - Product Identification and Installation Guide; Model Nomenclature

Model noMenClature
Category Code Item Code Position Code Designation & Description
Product Category 01 1 W = Water Source Heat Pump
Product Identier 02 2-4 LVC = R-410A, Floor Mounted, Standard Range
LVW = R-410A, Floor Mounted, Extended Range
Design Series (Vintage) 03 5 1 = Design Series 1
Nominal Capacity 04 6-8 072 = 72,000 Btuh Nominal Cooling
096 = 96,000 Btuh Nominal Cooling
120 = 120,000 Btuh Nominal Cooling
180 = 180,000 Btuh Nominal Cooling
215 = 215,000 Btuh Nominal Cooling
290 = 290,000 Btuh Nominal Cooling
Control Board Option 05 9 B = MicroTech® III Unit Controller
A = DDC-Less Board (Alerton Rep Option)
Network Module Option 06 10 L = Lon Module
B = BACnet
F = BACnet - WSHP System
Y = None
Condensate Overow Protection 07 11 S = Standard Overow Sensor
Freeze Fault Protection 09 13 F = Freeze Fault Protection
Voltage 11 15 D = 208-60-3
H = 230-60-3
K = 460-60-3
L = 575-60-3
Return Air 13 17 Y = Front Return
Discharge Air 14 18 T = Top Horizontal Discharge
U = Upblast Rear
F = Upblast Front
Blower Motor 15 19-20 01 = Belt Drive – Integral HP Motor
02 = High Static
04 = Ultra Static
Construction Type 17 23 A = Standard 1/2" Fiberglass Insulation
B = Closed Cell Foam Insulation
F = Standard 1/2" Fiberglass Insulation w/Compressor Sound Blankets
G = Closed Cell Foam Insulation w/Compressor Sound Blankets
Water To Refrigerant Heat Exchanger 18 24 C = Copper Inner Tube - Steel Outer Tube
Construction S = Cupro-nickel Inner Tube - Steel Outer Tube
Secondary Heating/Cooling Option 19 25 W = Waterside Economizer (Not to be combined with HGRH)
Dehumidication 20 26-27 AA = Hot Gas Reheat (Not to be combined with WSE)
YY = None
Piping Hand 21 28 L = Left Side Pipe Connections
R = Right Side Pipe Connections
Filter Options 23 32-34 SD1 = Standard 1" Disposable lter
M08 = Merv 8 in 2" frame
M13 = Merv 13 in 4" frame
N02 = No Filter with 2" Filter Rack (Low Leak)
N00 = No Filter-No Filter Rack
Condensate Drain Pan 27 41-42 GL = Galvanized Steel
SS = Stainless Steel
Control Transformer Option 29 44-46 050 = 50VA Control Transformer
075 = 75VA Control Transformer
www.DaikinApplied.com 3 LARGE VERTICAL WSHP IM 1059-12
